The LS221 is a 7075 Aluminum bodied multi-laser aiming device. Includes class IIIA visible laser in red or green and class 2M InfraRed laser coaxially mounted for easy zeroing. Also features a quick release picatinny rail mount, remote pressure switch, and IP67 water resistance.
In the Box:
- QD Release Mount
- Remote Cable Switch
- T10 L Key
- User Manual
- CR123A Battery
SPECS:
ELECTRONIC DATA |
|
Power Source | Battery |
Battery Type | CR123A |
Battery Life (Hours) | Up to modes |
Brightness Setting | Up to modes |
PHYSICAL DATA |
|
Window Size | N/A |
Dimension (in.) | 3.4″ × 1.9″ × 1.5″ |
Weight (oz.) | 6.7 |
MECHANICAL DATA |
|
Housing Material | 7075 T6 Aluminum |
Surface Finish | MAO |
Adjustment per Click | 0.5 MOA |
W&E Travel Range | ±50 MOA |
ENVIRONMENT DATA |
|
Storage Temperature | -40℃ – 65℃ |
Working Temperature | -40℃ – 51℃ |
Submersion | IP67 |
Vibration | 1000G |
LASER DATA |
|
Laser & Illuminator Type | Dual Laser |
White LED Output | N/A |
IR Illuminator Class | N/A |
IR Illuminator Output | 0.7mw |
IR Pointer Class | N/A |
IR Pointer Output | 0.1mw(low)/0.7mw(high) |
Visible Laser Class | IIIA |
Visible Laser Output | 1mw(low)/5mw(high) |
