INCLUDES:
- Thumbscrew Flattop Adapter (TA51)
- 3.5×35 Scopecoat (TA63)
- LENSPEN (TA56)
- Lanyard Assembly for Adjuster Caps (TA71E)
- Trijicon Logo Sticker (PR15)
- ACOG BAC Manual
- Warranty Card
FEATURES:
ALWAYS ON, ALWAYS READY
Most ACOG® models are battery free, featuring a tritium/fiber optic illuminated reticle that automatically adjusts the brightness based on available light.
TAKE CONTROL
Several ACOG models are designed with a user adjustable brightness setting powered by a single AA battery. The 3.5×35 LED and 4×32 LED models both offer six adjustable brightness settings.
RUGGED, RELIABLE HOUSING DESIGN
Fixed-power design allows for minimal moving parts to create a nearly indestructible sighting system.
“BOTH EYES OPEN” DESIGN
“Both eyes open” shooting using Trijicon’s Bindon Aiming Concept™ (BAC) feature allows for improved situational awareness.
OUTSTANDING CLARITY
The quality of the glass and multi-coated lenses maximize light-gathering capabilities and clear field of view with zero distortion.
EXACT TARGET DISTANCES & HOLDS
Most ACOG models feature a bullet drop compensating and target-ranging reticle for decisive aiming.
COMBAT PROVEN
No other magnified optic has been used more in combat than the ACOG.
SHOCK-RESISTANT
Proven to withstand recoil from a .22LR to a .50BMG and everything in between. Easily passes U.S. Military drop test requirements.
WATERPROOF
Exceptional waterproof performance that exceeds military standards. Dry nitrogen-filled to eliminate fogging. This optic is tested to withstand and perform in extreme cold and heat with dry-nitrogen filled housing that mitigates fogging.
SPECS:
Length x Width x Height: | 8 in x 2.1 in x 2.9 in (203.2mm x 53.34mm x 73.66mm) |
Weight: | 17.6 oz. (498.95g) |
Magnification | 3.5x | Objective Size: | 35mm |
Caliber: | .223 / 5.56 | Reticle Pattern: | Crosshair |
Day Reticle Color: | Red | Night Reticle Color: | Red |
Bullet Drop Compensating (BDC): | Yes | Bindon Aiming Concept™ (BAC): | Yes |
Illumination Source: | Fiber Optics & Tritium | Power Source: | Fiber Optics & Tritium |
Adjustment: | ½ MOA per click | Eye Relief: | 2.4 in. (60.96mm) |
Field of View (degrees): | 5.5° | Field of View (feet): | 28.9 ft. @ 100 yds. (9.63m @ 100m) |
Exit Pupil: | 0.39 in. (9.91mm) | Mount: | Flattop Thumbscrew Mount (TA51) |
Housing Material: | Forged Aluminum | Finish: | Matte Black |
